Boeing · B701

Boeing 707-100 specs, size & range

The Boeing 707-100 (ICAO code B701) is a landplane with 4 jet engines in the medium wake-turbulence category. It is 44.2 m long, a 39.9 m wingspan, a maximum take-off weight of 123,500 kg and a range of 5,556 km.

Landplane with 4 jet engines Wake category: Medium Airliners & big jets

707-100 specifications

Length: 44.22 m (145.1 ft)
Wingspan: 39.88 m (130.8 ft)
Height: 12.70 m (41.7 ft)
Wing area: 226.3 m² (2,436 sq ft)
Fuselage width: 3.76 m
Max take-off weight: 123,500 kg (272,271 lb)
Fuel capacity: 65,590 L (17,327 US gal)
Cruise speed: 540 kn (1,000 km/h)
Range: 3,000 nm (5,556 km)

The Boeing 707-100 is a landplane with 4 jet engines built by Boeing. Air-traffic control and flight-tracking sites identify it by the ICAO type code B701. It belongs to the medium wake-turbulence category.

707-100 size and dimensions

The 707-100 is 44.22 m (145.1 ft) long, has a wingspan of 39.88 m and stands 12.70 m tall. That makes it the #34 longest of 67 airliners & big jets in our database — longer than 49% of them. Its fuselage is 3.76 m wide, the width of a single-aisle cabin with six seats per row. With 226.3 m² of wing, the wing loading at maximum weight is about 546 kg/m².

707-100 weight and fuel

The maximum take-off weight is 123,500 kg (272,271 lb). Among airliners & big jets it ranks #34 of 69 by weight. The tanks hold 65,590 litres (17,327 US gallons), about 52.5 tonnes of jet fuel.

707-100 speed and range

It cruises at about 1,000 km/h (540 knots), faster than 98% of airliners & big jets. Its range of 5,556 km (3,000 nm) is enough to fly non-stop from London to Moscow (3,460 km) — about 5.6 hours at cruise speed.
