Zlín · Z22

Zlín Z-22 Junak specs, size & range

The Zlín Z-22 Junak (ICAO code Z22) is a landplane with one piston engine in the light wake-turbulence category. It is 7.3 m long, a 10.6 m wingspan and a range of 1,204 km.

Landplane with one piston engine Wake category: Light Piston & light aircraft

Z-22 Junak specifications

Length: 7.25 m (23.8 ft)
Wingspan: 10.60 m (34.8 ft)
Height: 1.96 m (6.4 ft)
Wing area: 14.7 m² (158 sq ft)
Fuel capacity: 72 L (19 US gal)
Cruise speed: 86 kn (159 km/h)
Maximum speed: 97 kn (180 km/h)
Range: 650 nm (1,204 km)
Service ceiling: 12,500 ft (3,810 m)

The Zlín Z-22 Junak is a landplane with one piston engine built by Zlín. Air-traffic control and flight-tracking sites identify it by the ICAO type code Z22. It belongs to the light wake-turbulence category.

Z-22 Junak size and dimensions

The Z-22 Junak is 7.25 m (23.8 ft) long, has a wingspan of 10.60 m and stands 1.96 m tall. That makes it the #19 longest of 26 piston & light aircraft in our database — longer than 27% of them.

Z-22 Junak speed and range

It cruises at about 159 km/h (86 knots), faster than 19% of piston & light aircraft. Its range of 1,204 km (650 nm) suits short regional hops — about 7.6 hours at cruise speed. Its ceiling is 12,500 ft (3,810 m).
