Douglas · DC7

Douglas DC-7 specs, size & range

The Douglas DC-7 (ICAO code DC7) is a landplane with 4 piston engines in the medium wake-turbulence category. It is 34.2 m long, a 38.9 m wingspan, a maximum take-off weight of 64,864 kg and a range of 9,069 km.

Landplane with 4 piston engines Wake category: Medium Piston & light aircraft

DC-7 specifications

Length: 34.21 m (112.2 ft)
Wingspan: 38.86 m (127.5 ft)
Height: 9.65 m (31.7 ft)
Wing area: 152.1 m² (1,637 sq ft)
Max take-off weight: 64,864 kg (143,000 lb)
Max landing weight: 49,000 kg (108,026 lb)
Fuel capacity: 29,620 L (7,825 US gal)
Cruise speed: 301 kn (557 km/h)
Maximum speed: 353 kn (654 km/h)
Approach speed: 110 kn (204 km/h)
Range: 4,897 nm (9,069 km)
Service ceiling: 21,700 ft (6,614 m)

The Douglas DC-7 is a landplane with 4 piston engines built by Douglas. Air-traffic control and flight-tracking sites identify it by the ICAO type code DC7. It belongs to the medium wake-turbulence category.

DC-7 size and dimensions

The DC-7 is 34.21 m (112.2 ft) long, has a wingspan of 38.86 m and stands 9.65 m tall. That makes it the #1 longest of 26 piston & light aircraft in our database — longer than 96% of them. With 152.1 m² of wing, the wing loading at maximum weight is about 426 kg/m².

DC-7 weight and fuel

The maximum take-off weight is 64,864 kg (143,000 lb) and it may land at up to 49,000 kg — 76% of take-off weight, so after a short flight it has to burn off fuel before landing at full weight. Among piston & light aircraft it ranks #1 of 16 by weight. The tanks hold 29,620 litres (7,825 US gallons), about 23.7 tonnes of jet fuel.

DC-7 speed and range

It cruises at about 557 km/h (301 knots), faster than 96% of piston & light aircraft. Its range of 9,069 km (4,897 nm) is enough to fly non-stop from Dubai to Beijing (7,900 km) — about 16.3 hours at cruise speed. On final approach it flies at around 110 knots (204 km/h). Its ceiling is 21,700 ft (6,614 m).
